Περιγραφή
- 6000VA / 5400W Online UPS with Power Factor 0,9
- Terminal Input, 4x IEC C13 Outlet, 2x IEC C19 Outlet, Terminal Outlet
- Backup time: 3,4min under full load and 9,8min under half load
- 19inch rack design with LCD
- Up to 2 units working in parallel also Battery Packs available
- With true double-conversion online UPS design, PowerWalker VFI 6000RT provides powerful and overall protection to your sensitive devices. It can accept wide input voltage for harsh environment. It offers full protection for critical devices such as sensitive servers, network/telephone communication systems as well as for industrial applications.
With its slim design it only requires 3U valuable space of your rack system. The UPS can be installed in 19” rack systems or used as tower.
Technical specification
General features Type Online Power capacity 6000VA / 5400W Output Power Factor 0.9 Input Input Voltage Range 120-276 VAC Depends on Load Level Max THDi <5% Input PF ≥ 0.99 at full load Frequency Range 45Hz – 55Hz or 54Hz – 66Hz Frequency (Synchronized Range) 45Hz – 55Hz or 54Hz – 66Hz Output Nominal Output Voltage 208/220/230/240 VAC Pure Sine Wave Yes THDv ≤2% Full Linear Load; ≤5% Non-Linear Load Voltage Regulation ±1% Frequency (Battery Mode) ±0,2Hz Parallel Work Up to 2 units of the same size Technical details Load Crest Ratio 3:1 Transfer Time [AC to Battery] 0ms Transfer Time [Inverter to Bypass] 0ms Transfer Time [Inverter to ECO] 1ms Transfer Time [ECO to Inverter] 10ms Bypass Before UPS Power-on: Default “No” Change to “Yes” via display panel
Overload und UPS Failure: Automatically transfer to bypass
By Setting: Voltage Rang: 120-276V ± 3%Generator support Yes Overload Capacity 2min @102%-130%; 30s @130%-150%; 100ms @ >150% External Battery Connection Yes Charger 1A Fan Logic Always on, automatic speed control LCD Indicators UPS status, Load level, Battery level, Input/Output voltage, AC mode, battery mode, Bypass mode, fault conditions; LCD Display colour : Blue, red, red flashing (depends on UPS status), direction swappable (rack/tower) Efficiency LINE mode full Load 93,3%% BATTERY mode full Load 89,0%% Energy Star compliance Yes
